CFW series vibrating feeder

CFW series vibrating feeder is used for transporting materials evenly and continuously from a silo to the equipment that receives the material. It is typically used in a crushing plant for feeding crusher evenly with also pre-scalping function. It is widely in crushing and screening plants in various industries such as metallurgy, construction materials, chemical industry, coal mines, beneficiation, abrasive materials etc.

Consultation hotline

0751-8721 999

Product featues Product photos Technical parameters Inquiry

Product featues

1. Optional grizzly configuration for pre-scalping and higher throughput, wide application in various industries

2. Simple structure, easy maintenance

3. Speed adjustment available by frequency converter, together with variable vibrating frequency to control the feeding speed.

4. Amplitude adjustment by increasing or decreasing the number of counterweights on the pulley and flywheel to adapt to needs of different conditions

5. Lithium-based grease for bearing lubrication, lower bearing temperature and lower noise level, greasing nipples located in the middle of bearings to achieve best lubrication effect.

Product photos

Technical parameters

Model	Feed chute specifications （mm）	Max. feed size （mm）	Capacity （t/h）	Vibrating frequency （t/m）	Amplitude （mm）	Motor power （kw）	Overall dimensions （mm）
CFW1220	1200×2000	800	360-500	855	7-9	11	2106×1976×870
CFW1520	1500×2000	1000	480-780	855	7-9	15	2106×2276×870
CFW1830	1800×3000	1200	600-980	855	7-9	18.5	3106×2576×870
CFW0940	900×4000	600	110-220	835	7-9	18,5	4148×1620×1160
CFW1150	1060×5000	750	230-340	835	7-9	22	5172×1780×1270
CFW1360	1300×6000	950	400-540	835	7-9	30	6172×2020×1270
CFW1570	1500×7000	1200	480-780	835	7-9	37	7183×2220×1450
CFW1870	1800×7000	1200	530-1300	835	7-9	55	7183×2520×1450
CFW2070	2000×7000	1200	600-1500	855	7-9	75	7183×2720×1450

Note: technical parameters are subject to change without prior notice.
